Specs
| Standard SKU: 970 73 50‑01 | |
|---|---|
| Cutting System | Standard SKU: 970 73 50‑01 |
| Cutting width | 54 in |
| Cutting deck type | Fabricated |
| Cutting methods | Collect/Mulch/Side discharge |
| Cutting deck material | Steel |
| Deck thickness | 7 gauge |
| Cutting height steps | 14 |
| Blade engagement | Electromagnetic clutch |
| Blade-tip speed | 18,500 fpm |
| Blade-tip speed | 94 m/s |
| Blades | 3 pcs |
| Anti-scalp wheels | 3 |
| Nose roller | No |
| Deck lifting system | Manual, foot activated |
| Cutting deck surface treatment | Powder coated |
| Spindle/mandrel type | Aluminium, commercial |
| Greasable mandrels | Yes |
| Deck Wash Port | No |
| Capacity | |
| Productivity | 4.3 acres/hr |
| Speed forward max | 10 mph |
| Speed forward min | 0 mph |
| Dimensions | |
| Base machine, height | 48 in |
| Base machine, length | 57 in |
| Base machine, width (chute down) | 68 in |
| Base machine, width (chute up) | 55 in |
| Weight | 1,176 lbs |
| Drive system | |
| Transmission type | Pump/Wheel motor |
| Transmission manufacturer | Hydro-Gear/Parker |
| Transmission model | HP1/DL |
| Pump displacement | 12 cm³ |
| Fan-cooled pumps | Yes |
| Engine | |
| Engine brand | Kawasaki |
| Motor/engine manufacturer | Kawasaki |
| Engine Power (As rated by the engine manufacturer) | 24.5 hp |
| Engine name | FX Series V-Twin |
| Cylinder displacement | 52 cu.inch |
| Cylinders | 2 |
| Engine cooling | Air |
| Air filter type | Heavy-Duty Canister Style |
| Power/fuel type | Gasoline |
| Engine lubrication type | Full pressure with oil filter |
| Oil filter | Yes |
| Fuel tank volume (with reserve) | 7 gal (US) |
| Fuel tank location | Side (Single) |
| Equipment | |
| Seat material | Vinyl |
| Seat back height | Low |
| Hour meter type | Yes |
| Cup holder | Yes |
| Seat type | Professional |
