Specs
US50/Can 967 32 93‑01 | |
|---|---|
Engine | |
Cylinder displacement | 25.4 cm³ |
Output shaft power1 | 1.36 hp |
Fuel tank volume | 17.25 fl oz |
Oil tank volume | 0.3 US pint |
Clutch engagement speed (±120) | 3,850 rpm |
Idling speed | 3,000 rpm |
Maximum power speed | 8,500 rpm |
Spark Plug | NGK BPMR8Y |
Torque, max. | 1.22 Nm |
Torque, max. at rpm | 6,700 rpm |
US50/Can 967 32 93‑01 | |
|---|---|
Emission | |
Exhaust emissions (CO₂ EU V)2 | 1,141 g/kWh |
US50/Can 967 32 93‑01 | |
|---|---|
Control | |
Connectivity | Not applicable |
US50/Can 967 32 93‑01 | |
|---|---|
Capacity | |
Chain speed at max power | 67.2 fts |
US50/Can 967 32 93‑01 | |
|---|---|
Equipment | |
Pitch | 3/8" mini |
Recommended bar length, max | 12 in |
Recommended bar length, min | 10 in |
Bar length (inch) | 12 in |
Nose type | Sprocket nose |
Chain type | H35 |
Harness | Single harness |
US50/Can 967 32 93‑01 | |
|---|---|
Dimensions | |
Weight (excl. cutting equipment) | 15.4 lbs |
Full length, including cutting equipment | 158.3 in |
Length, extended, including cutting equipment | 158.3 in |
Length, transportation mode - imperial | 113 in |
US50/Can 967 32 93‑01 | |
|---|---|
Sound and noise | |
Sound pressure level at operators ear (LpA) | 89 dB(A) |
Sound power level, guaranteed (LWA) | 107 dB(A) |
Sound power level, measured | 107 dB(A) |
US50/Can 967 32 93‑01 | |
|---|---|
Lubricant | |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
