Specs
28cc detachable shaft, single pack, 2024 SKU: 970 54 50‑02 | |
|---|---|
| Capacity | 28cc detachable shaft, single pack, 2024 SKU: 970 54 50‑02 |
Cutting width | 20 in |
| Dimensions | |
Weight (excl. cutting equipment) | 12.85 lbs |
Product size length | 72 in |
Tube diameter | 0.945 in |
Product size height | 10 in |
Product size width | 9.5 in |
Tube length | 59.291 in |
| Engine | |
Output shaft power1 | 1 hp |
Cylinder displacement | 28 cm³ |
Maximum rpm output shaft | 5,478 rpm |
Fuel tank volume | 17.82 fl oz (US) |
Fuel tank volume | 0.53 l |
Clutch engagement speed (±120) | 4,200 rpm |
Electrode gap | 0.02 in |
Fuel consumption | 543 g/kWh |
Idling speed | 3,000 rpm |
Maximum power speed | 8,000 rpm |
Spark Plug | Champion QCJ-8Y |
Torque, max. | 0.95 Nm |
Torque, max. at rpm | 7,000 rpm |
| Equipment | |
Harness | Not included |
Saw blade | Not included |
Trimmer head | Not included |
Grass blade | Not included |
| Sound and noise | |
Sound power level, guaranteed (LWA) | 116 dB(A) |
Sound pressure level at operators ear | 96.1 dB(A) |
| Vibration | |
Equivalent vibration level (ahv, eq) front handle | 5.97 m/s² |
Equivalent vibration level (ahv, eq) rear handle | 6.12 m/s² |
| Lubricant | |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Emission | |
Exhaust emissions (CO average) CARB | 0 g/kWh |
Exhaust emissions (CO average) EPA | 247 g/kWh |
Exhaust emissions (CO average) EU | 288 g/kWh |
