Specs
Fully assembled 967 10 84‑11 | |
|---|---|
Engine | |
Output shaft power1 | 2 hp |
Cylinder displacement | 38 cm³ |
Torque, max. | 1.84 Nm |
Torque, max. at rpm | 8,000 rpm |
Chain speed at max power | 55 fts |
Clutch engagement speed (±120) | 4,000 rpm |
Electrode gap | 0.022 in |
Idling speed | 3,000 rpm |
Ignition module air gap | 0.012 in |
Maximum power speed | 9,000 rpm |
Oil pump type | Automatic |
Spark Plug | NGK BPMR7A |
Fully assembled 967 10 84‑11 | |
|---|---|
Equipment | |
Recommended bar length, min | 14 in |
Pitch | 3/8" mini |
Recommended bar length, max | 16 in |
Chain type | S93G |
Bar length (inch) | 16 in |
Sprocket type | Spur 6 |
Gauge | .050" |
Fully assembled 967 10 84‑11 | |
|---|---|
Dimensions | |
Weight (excl. cutting equipment) | 10.36 lbs |
Fully assembled 967 10 84‑11 | |
|---|---|
Sound and noise | |
Sound pressure level at operators ear | 102 dB(A) |
Sound power level, guaranteed (LWA) | 116 dB(A) |
Sound power level, measured | 113 dB(A) |
Fully assembled 967 10 84‑11 | |
|---|---|
Vibration | |
Equivalent vibration level (ahv, eq) rear handle | 5.5 m/s² |
Equivalent vibration level (ahv, eq) front handle | 3.72 m/s² |
Fully assembled 967 10 84‑11 | |
|---|---|
Lubricant | |
Oil tank volume | 0.549 US pint |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Fully assembled 967 10 84‑11 | |
|---|---|
Emission | |
Exhaust emissions (CO₂ EU V)2 | 804 g/kWh |
